绕组方式Winding Type —————————— Delta
霍尔电位角度Hall Effect angle ————————— 120º electrical angle

绝缘等级Insulation Class ———————— B
工作环境温度Ambient Temperature Range ——— -20℃~+50℃
绝缘电阻Insulation Resistance —————— 100MΩ Min.500V DC
介电强度Dielectric Strength ———————— 700VAC 1minute
